The STEDI Type X™ EVO has been completely re-engineered from the ground up, taking inspiration from the curved styling of modern vehicles and delivering it in a smaller, higher-performing driving light package. Designed to shake up the market once again, the Type X™ EVO brings a new level of design, output, and refinement to the STEDI driving light range.

Registered Design Number 201814836 & Registered Trademark.

Type X™ EVO 8.5 Inch | Flood Beam

Type X™ EVO 8.5 Inch | Spot Beam





THE REVEAL.



MORE LIGHT, MORE FEATURES.



With increased light output comes a wider range of features. The Type X™ EVO houses 44 LEDs set within a 3D lens, supported by updated heat sink technology designed to dissipate heat more effectively.

The multi-bezel design allows for a unique sealing structure, using a hidden structural seal beneath a precisely proportioned outer bezel. This creates added depth, shadow, and a more refined overall finish.

STEDI has also introduced a new level of presentation and sustainability through bespoke packaging design. Each spotlight is individually packed in a water-resistant hard case, finished with STEDI™ detailing across every side, giving the product a premium feel before it is even fitted to the vehicle.



SHAPING THE FUTURE.



For anyone wondering what the future of driving lights looks like, the Type X™ EVO makes a strong statement. It brings together finely considered craftsmanship and next-generation design, combining minimalism, clean detailing, and curves that complement the look of modern vehicles.

The Type X™ EVO carries a bold attitude while maintaining a timeless design. It reflects a forward-thinking approach to driving lights and pushes the boundaries of what a premium auxiliary light can be.

At first glance, the silhouette and metallic bezel are likely to stand out. But on closer inspection, the more considered design elements begin to reveal themselves.

The 3D primary lens is one of the most distinctive features. Step into sunlight and its purpose becomes clear. Similar to the sculpted surfaces found on modern vehicle doors, the lens has been shaped to reflect the glow of the sky through its upward-facing section, while the lower section captures the shadows and depth of the terrain ahead.

Even a slight change in angle can dramatically alter the visual effect.

And the design detail does not stop there.

The iconic black covers have also been updated with a next-generation design focused on tactility. Like the 3D primary lens, the black cover uses shadow and light as part of its appearance, but with sharper, more defined edges that create a striking effect across the piano black finish.

On closer inspection, the STEDI™ logo is embossed into the cover, continuing the multi-dimensional design theme throughout the product. The result is a driving light that feels as much like a sculptural design piece as it does a high-performance lighting product.



THERE ARE NO BAD OPTIONS.

The Type X™ EVO is available in separate dedicated flood and spot beam patterns, giving drivers the ability to mix and match their setup and take greater control over the beam pattern that best suits their driving style and needs.

Using more efficient technology from CREE’s XP range of LEDs, the Type X™ EVO delivers impressive performance across every key criteria while retaining the warmer tones associated with high-efficacy 5000K XP LEDs.

So, should you choose flood or spot?

For long-range driving on straight, open roads, a pair of Type X™ EVO spot beams may be the best option. This setup is designed to project light far down the road, creating a focused beam that reaches nearly as far as the eye can see.

A pair of spot beams provides up to 1470m of light throw, producing a strong tunnel of light for open-road driving.

The Type X™ EVO flood beam is designed for a very different purpose. It delivers a wide, flat lateral beam across the horizon, giving excellent visibility across the road and surrounding terrain. The key to the flood beam design is its peak intensity in the critical zone.

The critical zone refers to the distance needed to safely stop from 100km/h and avoid a potential animal strike. In most situations, drivers want at least 200–300m of correctly placed usable light in front of the vehicle. With more than 475m of elongated horizontal light from a single Type X™ EVO flood beam, this setup provides excellent visibility and confidence in a wide range of night driving conditions.

Pairing a Type X™ EVO flood with a Type X™ EVO spot creates a highly effective combination. It delivers both broad roadside visibility and long-range forward projection, making it a strong all-round setup.

With an even more intense beam pattern, the Type X™ EVO represents the next evolution of the STEDI™ driving light legacy.



THE NITTY-GRITTY.

WHAT'S IN THE BOX

• 1 x STEDI Type X™ EVO LED Driving Light (Spot or Flood)
• 1 x Protective STEDI Black Out Cover
• 1 x Graphite Grey Colour Fascia
• 1 x Deep Orange Colour Fascia
• Complete Stainless Steel fastener kit

Note: The above contents may vary depending on the individual or bundled product.



KEY SPECIFICATIONS

LED	44 x CREE XP20
RAW LUMENS	18920 (Single)
TESTED DRAW	11920 (Single)
AMP DRAW	12.5A@12V, 6.25A@24V
POWER DRAW
CANDELA	1,334,025cd
BEAM PATTERN	Flood, Spot
INGRESS PROTECTION	IP68 | Submersible up to 3m
COLOR TEMP (CCT)	5000K
VOLTAGE COMPATIBILITY	12v & 24v
LUMEN MAINTENANCE	50,000 LM-80
WEIGHT	3.3kg (each)

PHOTOMETRIC DATA - PAIR COMBO

50M	129.96Lx
200M	32.48 Lx
300M	14.4 Lx
400M	8.1 Lx
1000M	1.29 Lx
1140M	1 Lx





NIGHT DRIVING FOOTAGE.



OPTIONAL ACCESSORIES.

COLOUR FASCIA

Following in the footsteps of our well-renowned Type X™ PRO, we have brought the colour element across allowing personalisation of the inner fascia to suit



BLACKOUT/FILTER COVERS

Our initial launch will include the standard blackout covers such as the standard STEDI and infamous Smiley which are required in countries with strict road regulations surrounding auxiliary driving lights. Also available are amber, green, and blue filter covers which alter the lights output colour temperature to assist with visibility in different driving conditions.



ANTI-THEFT KIT

For those wanting that little bit of extra protection, we offer a complete comprehensive anti-theft kit for that extra peace of mind having security keyed nuts and bolts ensuring a complicated time for those looking to rob you of your new driving lights.
